What is Nitinol?

Nickel Titanium (also known as Nitinol or NiTi) is in the unique class of shape memory alloys. A thermoelastic martensitic phase transformation in the material is responsible for its extraordinary properties. Nitinol alloys are typically made of 55%- 56% Nickel and 44%-45% Titanium. Small changes in composition can significantly impact the properties of the material.

There are two primary categories of Nitinol. The first, known as "SuperElastic", is characterized by extraordinary recoverable strains and kink resistance. The second category, "Shape Memory" alloys, is valued for the Nitinol's capacity to recover a pre-set shape when heated above its transformation temprature. The first category is often used for fishing. Aone Metal makes shape memory alloys, which are primarily useful for actuators, used in many different mechanical devices.

Application of Nitinol

Free recovery
Constrained recovery
Work production
Superelasticity
Thermal and electrical actuators
Biocompatible and biomedical applications
Damping systems in structural engineering
Other applications and prototype

Why Use Nitinol ?

Nitinol is used to manufacture catheter tubes, guidewires, stone retrieval baskets, filters, needles, dental files and archwires and other surgical instruments.Nitinol is an especially valuable alloy because it is extremely elastic and can change shape depending on temperature. This means that when Nitinol is cool (martensitic), it is bendable and exceptionally soft, and when it is warm (austenitic), it is rigid and super elastic.

Nitinol Produts

Wire -	Dia(0.05- 4.0)*L  mm
Sheet -	As per specification
Properties -	Super elastic and Shape memory
Standard -	ASTM F2063-12, GB/T 24627-2009

Nitinol Grade

Grade - Ni-Ti

Chemical Composition

Compound Formula	NiTi
Appearance	Metallic solid in various forms
Melting Point	1300 °C
Boiling Point	N/A
Density	6.45 g/cm3
Solubility in H2O	N/A
Poisson's Ratio	0.33
Specific Heat	0.20 cal/g·°C
Tensile Strength	895 MPa (Ultimate, fully annealed)
Thermal Conductivity	0.18 W/cm (austenite), 0.086 W/cm (martensite)
Thermal Expansion	11.0 x 10-6/°C (austenite), 6.6 x 10-6/°C (austenite)

Value Addition

Cut to length:Sheets/Rods/Pipes can be supplied in full sizes or cut to length as required by the clients.

Polishing:Sheets/Rods/Pipes can be polished is required by clients. It can also be provided in mill black finish if acceptable by clients.

Threading: We can also providing external threading to the bars if required by the clients.

Fabrication: We can fabricate the materials according to the customer’s needs.

Machining:We use CNC lathe machines to produce customized designs according to the client’s needs.

Heat Treatment: To change the mechanical properties of steel pipes and make it suitable for some applications, steel pipes can also a undergo heat treatment process.

Positive Material Identification: We have an PMI machine to identify all the Steel Plates while arrival and dispatch so as the pipes match to order specifications and client requirements.
