Molybdenum is gray-metallic and has the third-highest melting point of any element next
to tungsten and tantalum. It is found in various oxidation states in minerals but does
not occur naturally as a free metal. Molybdenum allows readily to form hard and stable
carbides. For this reason, Molybdenum is frequently used for making steel alloys, high
strength alloys, and superalloys. Molybdenum compounds usually have a low solubility in
water. Industrially, they are used in high-pressure and high-temperature applications
such as pigments and catalysts. Molybdenum is the most commonly used of all refractory
metals, in part because it is the least expensive refractory metal.
Like tungsten, molybdenum is used in the medical field. However, because molybdenum is
less dense than tungsten, it is not used as often in radiation shielding applications.
But its higher thermal conductivity, lower thermal expansion coefficient and lower
overall density make it an ideal material for use in rotating x-ray anodes and CT
imaging systems. Molybdenum is better suited to diagnostic imaging than shielding
applications, but this refractory metal is just as indispensible to the medical field
and its emerging technologies.
Molybdenum tube (pipe) can be used at service temperature up to 1,800 degrees.
Used in components of electron tube, heaters of high-temperature furnaces, thermocouple
retainers.
Defense
High Purity Materials
Metals
Nuclear Energy
Refractory Metals & Alloys
Research and Laboratory
Space
Solar Industry
Molybdenum is generally alloying element with steel in order to make that steel stronger. In fact, when molybdenum is added to even small steel concentrations, the result is an ultra-high-strength steel that will maintain structural stability when placed under pressures reaching as high as 300,000 lbs/sq. in.
(1) Molybdenum and alloys
| Rods - | Dia (0.8-120)mm*L |
|---|---|
| Discs - | As per specification |
| Tubes - | OD (1.0-50)mm* T(0.1-5)mm×(50-1000)mm |
| Wire - | Dia (0.05-5)mm*L (Best-selling size: 0.18mm, 0.2mm, 3.17mm.) |
| Sheet - | T (0.05-50.5)mm*W(50-600)mm*L(100-3000)mm |
| Crucible - | As per specification |
| Fasteners - | As per specification |
(2) TZM: Titanium-Zirconium-Molybdenum / Molybdenum Copper
| Wire, sheet, rod, plate and special shape products can supplied according to customers’ request. |
(2) Molybdenum lanthanum (lanthanum trioxide content 0.4-0.7%)
| Wire, sheet, rod, plate and special shape products can supplied according to customers’ request. |
Chemical Composition of TZM
| Others | O | Al | Fe | Mg | Ni | Si | N | Mo |
| Content (wt, %) | ≤0.03 | ≤0.01 | ≤0.002 | ≤0.002 | ≤0.002 | ≤0.002 | ≤0.002 | Bal. |
|
Grade |
The impurity content is not more than % |
|||||||
|
Fe |
Ni |
Al |
Si |
Mg |
C |
N |
O |
|
|
Mo-1 |
0.01 |
0.005 |
0.002 |
0.01 |
0.005 |
0.01 |
0.003 |
0.008 |
|
Mo-2 |
0.01 |
0.005 |
0.005 |
0.01 |
0.005 |
0.01 |
0.003 |
0.02 |
Cut to length:Sheets/Rods/Pipes can be supplied in full sizes or cut to
length as
required by the clients.
Polishing:Sheets/Rods/Pipes can be polished is required by clients. It
can also
be provided in mill black finish if acceptable by clients.
Threading: We can also providing external threading to the bars if
required by
the clients.
Fabrication: We can fabricate the materials according to the customer’s
needs.
Machining:We use CNC lathe machines to produce customized designs
according to the client’s needs.
Heat Treatment: To change the mechanical properties of steel pipes and
make it
suitable for some applications, steel pipes can also a undergo heat treatment
process.
Positive Material Identification: We have an PMI machine to identify
all the
Steel Plates while arrival and dispatch so as the pipes match to order
specifications and client requirements.
