Kaizen supplies instrumentation fittings in suitable material grades, sizes, pressure classes, and finishes with inspection and documentation support for the intended application.
Review the material routes, common standards, grade families, and service notes used for this product category.
Instrumentation Fittings is selected where product geometry, material grade, dimensional fit, and documentation need to match the final service requirement.
| Parameter | Typical Range | Notes |
|---|---|---|
| Tube size | 1/8 in to 2 in | Metric and inch OD combinations can be reviewed |
| Connection type | Compression and instrumentation fitting patterns | Selected to suit service and assembly |
| Forms | Union, elbow, tee, adaptor, reducer | Depends on line configuration |
| Material route | Stainless, duplex, monel, hastelloy and alloys | Matched to corrosion and pressure duty |
Tube fittings are selected for repeatable installation and dependable sealing in small-bore systems.
Fitting material, size, and pressure capability are aligned to tubing system design.
Used in analyzers, instrument hook-up lines, control panels, gas service, and hydraulic impulse connections.
Our team reviews product form, material grade, dimensional requirement, testing scope, and delivery schedule before issuing the technical offer.
